Products

Ultra Thin Light Box


Ultra thin

LED lighting, energy efficient

Aluminum frame for tool-free, easy poster changes

High quality, durable

Custom sizes and finishes available

Clear cover available

Ultra Thin Light Box

Ultra thin light box adopts the light guide plate engraved by CNC LMDE technology. The Laser controlled by CNC, engraves the face of acrylic plate and creates a large number of micro dots, which diffuse the light from the edge LED strip. Ultra thin light box provides a bright, uniform illumination that displays high quality poster with brilliant true colors.


Features:

Ultra thin

LED lighting, energy efficient

Aluminum frame for tool-free, easy poster changes

High quality, durable

Custom sizes and finishes available

Clear cover available

Specifications:

Art. No.

Frame size
(L x W x D mm)

Poster size
(L x W mm)

Visual size
(L x W mm)

Power
(W)

Weight
(KG)

WD10-1 A2

608 x 434 x 15.5

594 x 420

568 x 394

7.2

1.9

WD10-1 A1

873 x 626 x 20.5

841 x 594

817 x 570

14.4

4.0

WD10-1 A0

1221 x 873 x 20.5

1189 x 841

1165 x 817

21.6

5.6

Note: Other sizes could be customized.

Packing:

Air bubble film or corrugated carton. Recycled wooded pallet and recycled wooden box are available as demand.

Delivery:

Delivery time:  1 – 15 working days.

Port: Shanghai/Ningbo/Hangzhou

FAQ:

1. Are you a factory?

A: We are a factory, and we provide the OEM/ODM services.

2. Could I place a sample order for testing?

A: Yes, we could accept the sample order.
